OBD II Scan Tool Comparison of services used by the different standards SAE J1979 – 10 Services SID 1 to SID A (Service ID) SAE J1939 – 30 Services of DM 01 to DM 52 (Diagnostic Message) required data stream parameters from J1939-5 – 4 UDS* Services plus parameters In-Use Performance Ratio Tracking - Engine Run Time Tracking In-Use Performance Ratio Tracking 0B - Engine Run Time Tracking infoįunctional requirements (3) Required CCR 1971.1 functions using SAE J1939 - Readiness Status
#J1939 freeze frame iso
49/2008 (HD): ISO 27145-3 SAE J1939-73Ĭonclusion: In the future a Generic Scan-Tool must support all 3 standards SAE J1979, SAE J1939 and ISO 27145.įunctional requirements (1) Functional requirements for an OBDII Scan-Tool according to CCR 1968.2 and CCR 1971.1 - Readiness Status - Data Stream - Freeze Frame - Fault Codes (pending, confirmed, permanent) - Test Results - Vehicle Information (CALID, CVN, VIN, ECUNAME, ESN) - In-Use Performance Ratio Tracking - Engine Run Time Trackingįunctional requirements (2) Required CCR 1968.2 functions using SAE J1979 - Readiness Status
Regulatory requirements (5) Required standards for diagnostic communication protocols: CCR 1968.2 (LD): CCR 1971.1 (HD): Test equipment and diagnostic tools needed to communicate with OBD systems shall meet or exceed the functional specification given in ISO 15031-4 or SAE J1939-73 paragraph 5.2.2.1.
#J1939 freeze frame series
Access to OBD informationĪccess to OBD information shall be provided using, at least one of the following series of standards mentioned in Appendix 6: a) ISO 27145 (CAN-Bus) b) ISO 27145 (TCP/IP) c) SAE J1939-71Īnnex 9A 6.8.3. … emission of gaseous and particulate pollutants from compression-ignition engines for use in vehicles, and the emission of gaseous pollutants from positive-ignition engines fuelled with natural gas or liquefied petroleum gas for use in vehiclesĪnnex 9B (WWH-OBD, GTR Nr. Regulatory requirements (4) UN/ECE Regulation Nr. 83/2008 Uniform provisions concerning the approval of vehicles with regard to the emission of pollutants according to engine fuel requirementsĪnnex 11 Appendix 1 Section 6.5 Diagnostic signals One of the following standards with the restrictions as described must be used as the on-board to off-board communications link: a) SAE J1850 b) ISO 9141-2 c) ISO 14230-4 d) ISO 15765-4 Regulatory requirements (3) UN/ECE Regulation Nr.
shall be implemented in accordance with the specifications in SAE J1979 or SAE J1939 to allow for access to the required information by a scan tool meeting SAE J1978 specifications or designed to communicate with an SAE J1939 network. (3.2) SAE J1939 This protocol may only be used on vehicles with diesel engines. (3) Communications to a Scan Tool (3.1) ISO 15765-4 All required emission-related messages using this protocol shall use a 500 kbps baud rate.
#J1939 freeze frame code
Regulatory requirements (2) California Code Regulation 1971.1 On-Board Diagnostic System Requirements for 2010 and Subsequent Model-Year HeavyDuty Engines (HD OBD). shall be implemented in accordance with the specifications in SAE J1979 to allow for access to the required information by a scan tool meeting SAE J1978 specifications.
All required emission-related messages using this protocol shall use a 500 kbps baud rate. …required on all 2008 and subsequent model year vehicles. Regulatory requirements (1) California Code Regulation 1968.2 Malfunction and Diagnostic System Requirements for 2004 and Subsequent Model-Year Passenger Cars, Light-Duty Trucks, and Medium-Duty Vehicles and Engines (OBD II) World Wide Harmonization of On-Board Diagnostics Greg Potter, Director Automotive Division DG TECHNOLOGIES 23 rd October, 2012 1Īgenda Ø Regulatory requirements for an OBD Scan-Tool Ø Functional requirements of US13 and EU6 based on SAE J1979, SAE J1939 and ISO 27145 Ø Communication concepts of J1979, J1939 and ISO 27145 Ø Related standards and layer hierarchy of J1979, J1939 and ISO 27145 Ø Introduction into ISO 27145 WWH-OBD Ø OBD related standards for ISO 27145 Ø Comparison of functions and data of SAE J1979, SAE J1939 and ISO 27145 Ø Characteristics of the fault memory in WWH-OBD Ø Summary 2
